220/440 Volt, 3 Phase
Swing over table 10″
Table travel (Power feed) 24″
(4) Speeds of table travel 12,24,36, & 48
Table travel with reciprocator 0-3″
Reciprocator speeds to table 25,50,75,& 100
Angle settings of table -+ 5
Table working surface 5 x 42
Swivel of work head 90
Hole thru work head shaft 13/16
Collet capacity 5/8 Max
Removed table and spindle assembly, cleaned all way surfaces
Updated Bijur lubrication system to ways
New cross feed screw and nut
Re-aligned head stock and I.D.spindle to proper center heights
Table and spindle slide ways were rescraped
Cleaned, Painted and Cycled
Electric motors were serviced
Delivery 1 week
