220/440 Volt, 3 Phase
Swing Over Table 6″
Distance Between Centers 18″
Floor Space 106″ x 50″
Traverse Speed – 1PM High 240″/Low2″
Traverse Per Turn of Handwheel 0.200″
Traverse Handwheel Graduations 0.001″
Swivel Table Degree’s Include Angle 20
Headstock Speed Live 60,90,150,225,400,600
Standard Grinding Wheel Size 16″ x 1″ x 5″
Max Wheel Width 3″
Min Dia worn Wheel 9/12
Minimal backlash in feed screw and nut
Removed table and sub-table assembly, cleaned all way surfaces, re-assembled
Hydraulic pump Rebuilt, cylinder,valves,etc. cleaned and flushed, repaired as needed
All motors, switches, enclosers, sealtite, fittings repaired as needed
Cleaned and flushed lubrication system to ways
Cleaned, painted and Cycled
Runs and SOunds like New
All Feeds and Speeds are Functional
Delivery 2-3 Weeks
