Catalog Specifications
- Swing over table, maximum: 24-1/2″
- Swing inside coolant splash guard, maximum: 20″
- Grinding stroke, maximum: 16″
- Work head cross travel: 17-1/2″
- Work head longitudinal adjustment on bridge: 12″
- Wheel head slide longitudinal Travel: 20″
- Wheel head slide cross travel: 1-1/2″
- Work head flange to wheel head slide: 0″ to 30″
- Table longitudinal feeds, variable: 0 to 18 FPM
- Angular adjustment of work head: 90 Degrees
- Work head speeds, variable: 0 to 500 RPM
- Wheel head motor, horsepower: 5 HP
- Work head motor, horsepower: 1-1/2 HP
- Hydraulic motor, horsepower: ½ HP
- Coolant motor, horsepower: HP
- Electrics: 220/440/3/60
- Approximate machine dimensions: 91″ x 96″
- Approximate machine height: 75″
- Approximate machine weight: 6,200
